Amplifier
ADSP-800-1000-1500-2000
- Package: Yes
- Model ADSP-800-1000-1500-2000
- Maximum Power Per Channel: Above 200W
- Origin: Mainland China
- Product description:
| Specification | ||||
| Model:ADSP-800-1000-1500-2000 | ||||
| 2000W | 1500W | 1000W | 800W | |
| Stereo 8Ohms: | 2*2000W | 2*1500W | 2*1000W | 2*800W |
| Stereo 4Ohms: | 2*3600W | 2*2500W | 2*1700W | 2*1500W |
| 8 ohm Bridge | 1*6000W | 1*4500W | 1*3000W | 1*2500W |
| 4 ohm Bridge | / | 1*7000W | / | 1*3500W |
| Frequency Response | 20Hz –20kHz(0.5~-1.2dB) | |||
| THD% 10%Rated Power,1KHz: | <0.05% | |||
Slew Rate Rated Power,1KHz: | >22V/μs | |||
Damping Factor Rated Power,1KHz: | >1000(100Hz) | |||
| S/N: | >105dB | |||
| Sensitivity Rated Power,1KHz: | 0.77V/1.4 V | |||
| input lmpedance: | Balance 20K/Unbalance10K | |||
| Protection: | DC,Overheat,Short Circuit,Pressure Limit | |||
| Cooling: | Smart Fan Cooling System Control, Variable speed fans | |||
| Output Circuit: | CLASS D | |||
| Input/Output Connector: | XLR+SPEAKON+ACK(OPTIONAL) | |||
| Voltage: | AC90-265V/50/60Hz. | |||
