FP10000Q Power Amplifier

High quality 4 Channel 4x2500 Watts Class FP 10000q Line Array Sound System Audio Professional Disco Dj Power Amplifier FP10000Q

1. DC protection

2.  Short Circuit Protection

3.  Over Heat Protection

4.  Input Overload Protection

5. Output Overload Protection

6. Over Voltage Protection

7.  Low Voltage Protection

8.  Inductor resonance overpressure protection

   Specification
   Model  ：	FP10000Q
   Watts per channel  :	8Ω*   1300WX4	4Ω**   2100WX4
   Bridge mode  :	8Ω**  4200WX2	4Ω**   5000WX2
   Frequency Response :	20~20kHZ(-1.5dB)
   THD+N :	<0.05%
   S/N  :	>90dB
   Damping Factor :	>800(100Hz)
   Slew Rate :	10v/ūs
   Input Sensitivity :	0.775v/1v/1.4v/38dB/32dB/26dB
   Weight :	<16kg
   Remark:      1.*,The power is tested under EIA standard.                     2.**,Theper data is tested under the condition of 40ms burst,1KHz sine wave and 1% THD.                     3.Other data is tested under Q/SAE 1-2005 stangard.
