CM602A Double 6 Inch Passive LoudSpeaker -
- Double 6 Inch Passive LoudSpeaker
- 2-way loudspeaker
- RMS power：320w
- Built-in DSP Amplifiers
- Product description: CM602A Double 6 Inch Passive LoudSpeaker
Portable, versatile powered column speakers
Dual 6.5 inch coaxial speaker drivers
Built-in Hi-Fi class amplifier module, excellent DSP function
Heart-shaped sound diffusion design for cabinet
| Specification: | |
| Components ： | 2 x 6" (160 mm) ferrite LF driver. Coaxial 2 x 1" exit, 1"coil compression driver |
| H×W×D ： | 440mm(17.4inch) x 590mm(23.3inch) x 407mm(inch) . |
| Weight ： | 10.3kg |
| Connectors ： | XLR male in & XLR female out |
| Finish ： | Plywood finished with textured black coating |
| Flying Points ： | M8 screw and Bracket |
| Stand fittings ： | YES |
| Frequency Response ： | 90 Hz - 19 kHz . |
| Sensitivity 1W @1m ： | 94dB |
| Nominal Peak SPL @1m ： | 116 dB. |
| Crossover Frequencies ： | 2.6kHz. |
| Nominal Impedance ： | 2 x 8Ω, HF 2 x 8Ω |
| Amplifiers : | LF 160W/4Ω , HF160W/4Ω |
| AC power ： | 110V/60Hz,220V/50Hz Optional |
