SUB6000-DSP Amplifier Module
- 2 CH amplifier
- RMS Power 3000W*2
- Built-in DSP processor
- 6 different presets
- Product description: 2 Channel GETSHOW 6000W Subwoofer Amplifier Module Professional Speaker Plate Amplifier Class D with DSP Audio Processor
*Professional 2 Channel CLASS-D amplifier.
*Built-in high-performance 48KHZ DSP audio processor, RS485 online or network adjustment.
* Free Software is offered
*110-230v general working voltage
*Full sealed with the box, can be installed without a partition.
*Widely used in professional subwoofer speaker, 2x12 inch，2x15 inch, 2x18 inch, 3x 18 inch
| Specification | |
| Model : | SUB6000 |
| Rated Power 8Ω : | 2*2000w |
| Rated Power 4Ω : | 2*3000w |
| Frequency Response : | DSP Control |
| THD 1KHZ : | ≤0.5 |
| Damping Fa ctor : | >200 |
| Slew Rate : | >20V/us |
| S/N : | >95dB |
| Sensitivity : | 0.775V |
| Input Impedance : | Balance 20K, Unbalance 10K |
| Output Topology : | CLASS-D |
| Protection : | Short circuit, DC, Overheat, Peak Pressure Limit, Soft Start |
| Voltage : | AC110-240V/50HZ-60HZ voltage-selected switch |
