HD6536-65mm HF compression driver ferrite - -

Features

160 W continuous program power capacity

1.4" horn throat diameter

65 mm (2.5 in) aluminium voice coil

Titanium diaphragm

1000 - 18000 Hz response

108 dB sensitivity

Shorting copper cap for extended HF response

Specification
Throat Diameter:	36mm(1.4in)
Minimum Impedance:	7.6 Ω
Continuous Power Handling:	160w
Sensitivity:	108dB
Frequency Range:	1 kHz - 18 kHz
Recommended Crossover:	1.2KHz
Voice Coil Diameter:	65mm (2.5 in)
Inductance:	0.15 mH
Flux Density:	1.55 T
Min Frequency Range:	1 kHz
Nominal Impedance:	8 Ω
Nominal Power Handling:	80 W
Winding Material:	Aluminium
Diaphragm Material:	Titanium
Max Frequency Range:	18 kH
Mounting and Shipping Info
Other details：	4x M6 Mounting Studs with bolts and washers include
Depth：	65 mm (2.5 in)
Shipping Units：	2 pcs
Shipping Box	150x150x170 mm （2 pcs）
Overall Diameter	140 mm (5.7 in)
Net Weight：	6.2 kg （2 pcs）
Shipping Weight：	6.4 kg （2 pcs）
