Introduction

LKS28 ----High power subwoofer



The LKS28 is a reference subwoofer designed to extend the frequency response of large format systems. The LKS28 features two high excursion, 18’’ direct radiating transducers mounted in a bass-reflex tuned enclosure. The L-Vents reduce turbulence and port noise at high levels while also increasing LF efficiency. The LKS28 operates from 25 Hz. The excursion capability of the transducer, combined with L-Vents contributes to deliver a high SPL, with low distortion. The LKS28 can offer standard or cardioid directivity, by combining physical deployment and the suitable preset.

Specification

Description

High power subwoofer: 2 × 18’’

Low frequency limit (-10 dB)

25 Hz

Maximum SPL

143 dB

Directivity

Standard or cardioid

Transducers

2 x 18’’ neodymium, aluminium die cast basket

Acoustical load

Bass-reflex enclosure, L-Vents

Nominal impedance

4 Ω

Connectors

IN: 4-point speakON

Weight (net)

82 kg

Cabinet

Premium grade birch plywood

Front

Coated steel grill
